SBS-compliant tube rack for use on liquid handlers to accommodate a range of tube types.  The standard diameter is 16.6mm for a variety of tubes such as 15ml centrifuge tubes (VWR, Axygen, BD, Corning, etc.), 12ml KIMAX Culture tubes, Oragene OG-500 tubes and Tyco Monoject Tubes. Custom sizes available from ca. 12 – 17 mm.



24 Position SBS Tube Rack

  • SBS footprint, compatible with standard liquid handler decks
  • Holds up to 24 tubes
  • Compatible with a range of tube types from 12 – 17 mm. Specify when ordering.

This tube rack is similar to our 15 ml tube rack, P/N A000260. However, the difference between them is that this rack has a closed bottom. 15 ml centrifuge tubes sit 0.5 mm above the deck.

We can build the rack for tube diameters ranging from 12 – 17 mm. Ideally, we like to have a sample tube to ensure a perfect fit, but you can also specify the diameter. Measure the tube diameter at 65 mm from the bottom.

Scientific Papers will be added soon.

Ready to buy your 24 Position Tube Rack (closed bottom)?
